华为ospf路由协议

1、<Huawei>system-view[Huawei]sysname R1[R1][R1]int髫潋啜缅erface loopback 1[R1-LoopBack1]ip address 1.1.1.1 255.0.0.0[R1-LoopBack1]interface serial 2/0/0[R1-Serial2/0/0]ip address 12.12.12.1 255.0.0.0[R1-Serial2/0/0]undo shutdownInfo: Interface Serial2/0/0 is not shutdown.[R1-Serial2/0/0]q[R1]q<R1>save<Huawei>system-view[Huawei]sysname R2[R2][R2]interface loopback 1[R2-LoopBack1]ip address 2.2.2.2 255.0.0.0[R2-LoopBack1]interface serial 2/0/1[R2-Serial2/0/1]ip address 12.12.12.2 255.0.0.0[R2-Serial2/0/1]undo shutdown[R2-Serial2/0/1]interface serial 2/0/0[R2-Serial2/0/0]ip address 23.23.23.2 255.0.0.0[R2-Serial2/0/0]undo shutdown[R2-Serial2/0/0]q[R2]q<R2>save<Huawei>system-view[Huawei]sysname R3[R3][R3]interface loopback 1[R3-LoopBack1]ip address 3.3.3.3 255.0.0.0[R3-LoopBack1]interface serial 2/0/1[R3-Serial2/0/1]ip address 23.23.23.3 255.0.0.0[R3-Serial2/0/1]undo shutdown[R3-Serial2/0/1]interface serial 2/0/0[R3-Serial2/0/0]ip address 34.34.34.3 255.0.0.0[R3-Serial2/0/0]undo shutdown[R3-Serial2/0/0]q[R3]q<R3>save<Huawei>system-view[Huawei]sysname R4[R4][R4]interface loopback 1[R4-LoopBack1]ip address 4.4.4.4 255.0.0.0[R4-LoopBack1]interface serial 2/0/1[R4-Serial2/0/1]ip address 34.34.34.4 255.0.0.0[R4-Serial2/0/1]undo shutdown[R4-Serial2/0/1]q[R4]q<R4>save查看接口配置信息R1#displayip interface briefR2#displayip interface briefR3#displayip interface briefR4#displayip interface briefOSPF配置<R1>sys[R1]router id 1.1.1.1[R1][R1]ospf 1[R1-ospf-1]area 1[R1-ospf-1-area-0.0.0.1]network 1.0.0.0 0.255.255.255[R1-ospf-1-area-0.0.0.1][R1-ospf-1-area-0.0.0.1]network 12.0.0.0 0.255.255.255[R1-ospf-1-area-0.0.0.1]return<R1>save<R2>sys[R2]router id 2.2.2.2[R2]ospf 2[R2-ospf-2]area 1[R2-ospf-2-area-0.0.0.1]network 12.0.0.0 0.255.255.255[R2-ospf-2-area-0.0.0.1]q[R2-ospf-2]area 0[R2-ospf-2-area-0.0.0.0]network 23.0.0.0 0.255.255.255[R2-ospf-2-area-0.0.0.0]network 2.0.0.0 0.255.255.255[R2-ospf-2-area-0.0.0.0]q[R2-ospf-2]q[R2]q<R2>save<R3>sys[R3]router id 3.3.3.3[R3]ospf 3[R3-ospf-3]area 0[R3-ospf-3-area-0.0.0.0]network 3.0.0.0 0.255.255.255[R3-ospf-3-area-0.0.0.0]network 23.0.0.0 0.255.255.25[R3-ospf-3-area-0.0.0.0]q[R3-ospf-3]area 2[R3-ospf-3-area-0.0.0.2]network 34.0.0.0 0.255.255.255[R3-ospf-3-area-0.0.0.2]q[R3-ospf-3]q[R3]q<R3>save<R4>sys[R4]router id 4.4.4.4[R4]ospf 4[R4-ospf-4]area 2[R4-ospf-4-area-0.0.0.2]network 34.0.0.0 0.255.255.255[R4-ospf-4-area-0.0.0.2]network 4.0.0.0 0.255.255.255[R4-ospf-4-area-0.0.0.2]q[R4-ospf-4]q查看邻居信息<R1>display ospf peer<R2>display ospf peer<R3>display ospf peer<R4>display ospf peer查看路由表信息<R1>display ip routing-table<R2>display ip routing-table<R3>display ip routing-table<R4>display ip routing-tableR1，R2，R3，R4学习到了网路中的所有网段的路由信息
